Pure Series Dry Bath

Product model:

Thermal Control Series

product details

The whole unit adopts safe voltage DC24V, ensuring absolute safety when operators come into contact with the aluminum module.

Easy to operate, with over-temperature power cut-off and alarm, rapid forced cooling to preserve precious experimental reagents.

Excellent temperature stability and uniformity ensure accuracy of experimental data.

PID digital temperature control, faster, more accurate, and more convenient temperature calibration.

OLED large screen display, presenting more parameters intuitively.

High-quality precision module processing ensures optimal thermal conductivity.

Simpler two-point temperature calibration, +/-5℃ zero calibration and span calibration.

One-key auto-tuning (AT) function for current environmental temperature parameters under different conditions.

Main Parameters
Parameter	Value
Product Model	H-100
Temperature Setting Range	0℃~100℃
Temperature Control Range	RT+5℃~100℃
Temperature Stability / 37℃	±0.3℃
Temperature Uniformity / 37℃	±0.3℃
Setting Accuracy	0.1℃
Display Accuracy	0.1℃
Temperature Control Accuracy	±0.3℃
Display Type	OLED
Heating Rate	25℃~37℃ ≤4min; 25℃~100℃ ≤15min
Cooling Method	Fan cooling
Time Setting	1~999sec / 1~999min / Hold (2 modes selectable)
Dimensions (mm)	L114 × W140 × H107
Input Power Supply	DC24V
Power	56W
Net Weight (Kg)	0.8Kg
Safety	Automatic power off and alarm upon overtemperature

Product Parameters
Pure H-100 series metal bath

Host Parameter
Product Model	Pure-H-100
Temperature Range	0°C~99.9°C
Temperature Control Range	RT+5°C~99.9°C
Temperature Stability /37°C	±0.3°C
Temperature Uniformity /37°C	±0.3°C
Setting Accuracy	0.1°C
Display Accuracy	0.1°C
Temperature Control Accuracy	±0.3°C
Display Mode	IPS touch screen
Heating Rate	25°C~37°C/3min;25°C~99.9°C/10min
Cooling Method	fan cooling
Set Time	1min-23h59min
Dimensions: Length x Width x Height	L114×W140×H107
Input Voltage	AC-220V
Input Power	56W
Net Weight (Kg)	0.8Kg
Security	overtemperature automatically disconnect power supply and alarm

Module item number	Product model	Configuration information	Standard equipment /Optional accessories
03H100001	Pure-H-100	Host machine	/
2303H100001-1	H-100-1	1.5ml centrifuge tube ×16 Wells + 0.2ml centrifuge tube ×32 Wells (φ10.724.7+φ6.3mm12.8mm)	Standard fitting
2303H100001-2	H-100-2	0.2ml96 Wells (φ6.517.5mm)	Fit and match
2303H100001-3	H-100-3	0.5 centrifuge tube ×40 Wells (φ8mm*21mm)	Fit and match
2303H100001-4	H-100-4	1.8/2ML cryostorage tubes ×24 Wells (φ12.3mm*24mm)	Fit and match
2303H100001-5	H-100-5	1.5/2ML tip bottom centrifuge tube ×24 Wells, (φ11mm*24mm)	Fit and match
