Top Magic Series Single Channel Heated/Unheated Magnetic Stirrer (Top1/Top1h)

Product model:

Magnetic Stirrer Series

MESSAGE

product details

Products using DC brushless motor, bottom noise, maintenance-free, smooth operation;

The rotor adopts strong magnetic and high temperature resistant magnetic steel to ensure suﬃcient attraction and torque of the instrument to prevent the rotor from jumping when the stirring rotor is running;

The upper and lower shells are made of integrated die-casting aluminum, and the surface is sprayed with ceramic technology, which is eﬀective in anti-corrosion and wear-resistant.

Single channel magnetic stirrer(unheated type）
Supply voltage	AC100-240V
Power	25W
Display Mode	LCD
Rotational Speed	200-1600
Speed control range	±10rpm
Eﬀective Centrifuge Time	1-99 hours 59 minutes
Maximum stirrer capacity	5L
Working disc material	Coated PC, corrosion resistance
Working plate area size	150*150
Motor type	Brushless DC motor
Time control mode	Left knob control
Speed control mode	Right knob controls

Single channel magnetic stirrer（Heated type)
Supply voltage	AC100-240V
Power	250W
Display Mode	LCD
Rotational Speed	200-1600
Speed control range	±10rpm
Eﬀective Centrifuge Time	1-99 hours and 59 minutes
Heating temperature	RT-105℃
Temperature control	Built-in temperature line
Maximum stirrer capacity	5L
Working disc material	304 Stainless steel
Working disc area size	150*150
Motor type	Brushless DC motor
Time control mode	Left knob control
Speed control mode	Right knob controls

Mini magnetic stirrer

Feature	Specification
Overall Power	12W
Display Type	Full-view High-definition Digital Tube
Speed Range	200-1800rpm
Speed Control Precision	±5%rpm
Allowable Ambient Temperature	-40°C to Room Temperature
Maximum Stirring Volume	≤2L
Standby Time	3.5-4 hours
Workplate Material	PVC Anti-corrosion Layer
Dimensions	165×40 mm
Motor Type	Micro Brushless Motor
Time Control Mode	Manual
Speed Control Mode	Touch key adjustment

Single/four channel heated/unheated magnetic stirrer

	Top1 Single-Channel Non-Heating	Top1H Single-Channel Heating	Four non-heated sections	Top4H 4-Channel Heating
Product model	Top1 Single-Channel Non-Heating	Top1H Single-Channel Heating	Four non-heated sections	Top4H 4-Channel Heating
Power supply voltage	AC100-240V	AC100-240V	AC100-240V	AC100-240V
Power	25W	250W	70W	300W
Display mode	LCD	LCD	LCD	LCD
Speed	200-1800rpm	200-1800rpm	200-1800rpm	200-1800rpm
Speed control range	±10rpm	±10rpm	±10rpm	±10rpm
Effective centrifugation time	1 - 23 hours and 59 minutes	1 - 23 hours and 59 minutes	1 - 23 hours and 59 minutes	1 - 23 hours and 59 minutes
Heating temperature	/	RT-105°C	/	RT-105°C
Temperature control	/	Built-in temperature line	/	Built-in temperature line
Maximum stirring capacity	2L	2L	2L	2L
Workpiece material	Corrosion resistance of AG glass	Anodized aluminum plate	Corrosion resistance of AG glass	Anodized aluminum plate
Workpiece plate size	180*190mm	180*190mm	215*235mm	215*235mm
Motor type	DC brushless motor	DC brushless motor	DC brushless motor	DC brushless motor
Control method	Knob control	Knob control	Knob control	Knob control
